Gree LTO Battery Cell 2.3V 110ah Prismatic Yinlong Lithium Titanate Battery For BESS
Parameters
| Battery Type | Lithium titanate battery |
| Nominal Voltage | 2.3V |
| Nominal Capacity | 110Ah |
| Max.Charge Voltage | 2.9V |
| Max.Discharge Voltage | 1.5V |
| Weight | 3000g |
| Cycle life | 16000 cycles |
| Cell-Level | Brand New Grade A |
| Dimension | 130*51*205mm |
| Internal Resistance | around 0.5mΩ |
Advantages of Lithium Titanate Battery
1. faster charging: 10mins fully charged
2. high discharge rate: as much as 10C-15C
3. wide working temperature range: -50°C ~ 65°C
4. super long cycle life: over 30,000 times
Detail Specifications
| Item | Parameters |
| Model | Gree Yinlong |
| Materials | LTO |
| Nominal capacity | 110Ah |
| Nominal voltage | 2.3 V |
| | 130*51*205mm |
| Dimension |
| | |
| Weight | 3000±50g |
| Internal Resistance | ≤0.5mΩ |
| Operating voltage | Charge cut-off voltage | 2.9 V |
| Discharge cut-off voltage | 1.5 V |
| Standard charge/discharge current | Charge current | 1C(110 A) |
| Discharge current | 1C(110A) |
| Maximum charge current | 3C 330A |
| Maximum discharge current | 3C 330A,500A for 10 seconds |
| Cycle life | 16000 times |
| Operating Thermal Ambient | Charging | -50℃~ 65℃ |
| Discharging | -50℃~ 65℃ |
| Storage Thermal Ambient | Short term(within 1 month) | -20℃~ 45℃ |
| Short term(within 1 year) | -20℃~ 20℃ |
What is LTO/Lithium titanate battery?
- Lithium titanate battery(LTO) is a kind of lithium titanate used as a negative electrode material for lithium ion batteries. It can be combined with lithium manganate,NCM materials or lithium iron phosphate to form a 2.4V or 1.9V lithium ion secondary battery.
- LTO battery is deep cycle with more than 25000 times.
- LTO lithium battery is one of the best options for solar energy system
- It's for street lamp,home power wall,solar system etc
Lithium battery won't lose capacity at extremely low temperature
LITHIUM TITANATE(LTO)
Spinel structure/Zero strain material
Lithium titanate has a stable 3D crystal structure,The material structure hardly changes in discharging&charging.
Compared to lithium battery with graphite as the negative electrode,LTO hardly results in SEI with poor stability that
happens on LFP,Avoiding thermal runaway caused by SEI during high-temperature decomposition, resulting in battery
fire and explosion.
Lithium titanate batteries have a higher potential for lithium metal,no lithium crystal occured,safer and better stability.
It's able to charge&discharge in high rate due to 3D lithium iion transist channel.Fully charge and discharge within the
range of -50 ° C extreme low temperature to 60 ° C ultra-high temperature.
Delithiation,LTO(volume change rate ± 3%),25000 times life
Frequent delithiation,Graphite volume increases(volume change rate ± 3%),reducing life cycles
Safety & Stability
LTO,NO SEI
Other lithium,SEI
Low reactivity between lithium titanate and electrolyte,No SEI,higher safety and stability.
Stabbing Over Charging%Dischagring
Stabbing under water Drilling
Cutting Fire test
Fast charging
Wider range
Full charge at -50 degree
