10S Lithium Battery Bms

Waterproof LTO BMS 36V 10S 80A PCB PCBA BMS System With Balance Common Port For Solar Storage Energy

Overview

This BMS is customized for 3~32S LTO battery pack.

We can design BMS for various lithium batteries like LiFepo4, LiMn2O4, LTO, and Li-polymer etc.

The main functions are: over charge protection, over discharge protection, over current protection, short-circuit protection, temperature protection etc.

Technical Parameters

Advantages

1. Use top quality (A-level) protective integrated circuit IC, from the solution of Seiko of Japan.

2. Strong load ability, constant discharge current 80A , use high voltage resistance, low inner

resistance power Mosfet. The heat sink will greatly help cooling.

3. IC itself has power balancing function. The circuit is simple and reliable.

4. Typical voltage detection for each cell. So each battery will be prevented over charged or over discharged. Over current and short circuit protection

function is very reliable.Long time short circuit of the load won’t affect the PCB and the battery.Temperature protection during charging and discharging.

5. Extreme low power consumption.

6. PCB use high anti-corrosion, high water resistance, high impedance ESD conformal Coating

Detail Descriptions

Model: DL 10S (2.3V Rated LTO Battery Pack )

common Version : common port for charge/discharge

What is the balance function?
The working principle and function are as followings, when your one cell voltage is upto alarm voltage(Li-ion upto 4.18V, Life Po4 upto (3.6V), then the cell Balance starts to work, balance resistance starts discharge with 35ma(when balance discharge starts to work, BMS will starts a little heat up, which is the normal reflection), the cell is in both charging and discharging status, and others which are not reached to alarm voltage(Li-ion 4.18V, Life Po43.6V)are only in charging status, no discharging, when the fast cell voltage is reached to alarm voltage (Li-ion 4.25V, Life Po43.75V)BMS starts off power protection, all the other cells
are all in stop of charging, this process will enable your battery charging in balance current, and your battery voltage are in balance status, but when your cell voltage difference are in a big range, then balance can not be functionning.

Package

1) Different package is base on the quantity of your order.
2) We cooperate with DHL, FEDEX, UPS, EMS, ePacket for delivery, you can choose one that you prefer.
3) If you prefer China Post or HKDHL for delivery, contact me please.
4) If you have special requests(such as declared value, extra remark), please contact me in advance or leave message along with order.

Our Service and Strength

Stable performance, cost-effective products, high-quality and superior service, our products have not only gained a good reputation in the country, but also received high-quality evaluation in France, Germany, Russia, the United States, South Korea and other countries.
1). Rigorous quality assurance system.
2). High level of service awareness.
3). High quality team.
4). Components use well-known brands.
5). Quick response customer program.
6). Self-owned processing plant, rapid production, equipped with automatic SMT placement machine, automatic screen printing machine and reflow oven.

About Deligreen

Changsha Deligreen Power Co.ltd,founded in 2010, is a "Green Energy Solution Service Provider".
Newest technology, new idea,hard-working and honest people,
Focus on lithium rechargeable battery, BMS,Balancer,charger and relative products.
Main application: electric bicycle, scooter,motorhome, AGV,solar/wind system, Energy storage system,truck and so on.
Four Promises:
We promise "Real" lithium capacity
We promise u100%n refund for any quality problem We promise11100%" replacement for any shipping damage
We promise lifetime fast technical support Customers, satisfaction is our endless pursuing.

RAQ

1. What's the MOQ?
There is no MOQ for samples. For bulk order quantity, the more, the cheaper.

2. How about the lead time?
Usually, we have stable stock in wharehouse. The goods can be sent within 2-7 days.

3. How long of the shipping time?
It always need 3-10 days by express such as DHL and UPS, 15-50 days by China Post , 20-30 days by sea.

4. Can you produce the order with the customer's brand?
Yes, of course. OEM & ODM service is warmly provided.

LTO80A PCB lithium battery bms

PCB 10S lithium battery bms

MSDS 10S Lithium Battery Bms

10S Lithium Battery Bms Images
